Case Study

CURRIE COMMUNITY
HIGH SCHOOL

Location

Edinburgh

Material

Bauder - Reinforced Bitumen Membrane Roof

Richard Austin Alloys - Aluminium Serrated Prefa Zakenprofile

Taylor Maxwell - Anvil Planks & CGL VM Zinc Interlocking Wall Planks

Euroclad - Prisma 38/914 Ephyra Liner Sheets

Client

Kier Construction

Duration

August 2023 - April 2025

Sector

Education

Value

£6.5M

Working with Procladd has been a very positive experience overall. Throughout the tender process and into project delivery, the team demonstrated a high level of professionalism and a proactive approach. Although the contract finalisation stage took longer than expected, with several issues arising that delayed signing, we appreciated that Procladd continued to progress design work during this period. This commitment was both helpful and reassuring. The quality of workmanship and attention to detail were consistently strong. It was clear that Procladd were focused on delivering a high quality project, and their dedication to achieving the best possible outcome was evident throughout. As a subcontractor, they fulfilled their role effectively and met our expectations in terms of service and product quality. Procladd provided a timely and reliable service, and despite a few challenges along the way, the overall experience was very positive. Communication was constructive, and the team remained committed to supporting the project’s needs. We would have no hesitation in recommending Procladd for future roofing and cladding works. Their professionalism, quality of service, and collaborative approach make them a strong partner for upcoming projects.

Richard Cairns, Senior Project Manager - Kier Construction

£1.8M

Generated Social Value.

14,500m2

Facility Footprint.

70%

Less energy than traditional school builds.

Case Study: Currie Community High School

As part of the £65m redevelopment of Currie Community High School, Procladd delivered the full roofing and cladding package for one of Scotland’s first Passivhaus‑designed secondary schools. Designed by Architype and built by Kier Construction for the City of Edinburgh Council, the 14,500m² facility is expected to use 70% less energy than a traditional school and forms a key part of Edinburgh’s ambition to reach net‑zero by 2030.

The project integrates extensive community facilities including a leisure centre, theatre, café, outdoor learning areas, a sensory garden, and a Passivhaus‑certified swimming pool—creating a landmark space for both students and local residents.

Our Scope: A £6.5m Roofing & Rainscreen Cladding Package

Procladd were responsible for delivering a comprehensive multi‑system envelope package, including:

6,000m² of Bauder felt roofing
Eurooclad Prisma Ephyra liner sheets to external canopies
2,600m² of rainscreen cladding, featuring:

2,300m² Prefa Aluminium Zakenprofile (Bronze finish)
166m² Anvil “Blood Red” feature planks
207m² VM Zinc “Pigmento Red” interlocking planks

Supporting materials included Rockwool DuoSlab insulation, Hilti bracket and rail systems, PFC Corofil fire barriers, and SFS fixings—each selected to achieve the performance required for Passivhaus certification.

Delivering Passivhaus Performance: Precision, Detail & Zero Tolerance

The project required the entire building envelope to support rigorous Passivhaus standards, ensuring exceptional airtightness, thermal continuity, and long‑term energy efficiency.

Reducing Thermal Bridging Across the Envelope

Working closely with Architype, our design team:

Developed junction details that eliminated cold bridging across all roofing and façade zones
Reduced fixing penetrations to maintain airtightness
Coordinated clerestory roofs and stair cores in bronze Prefa cladding
Ensured precise thermal alignment across the 6,000m² roof and 2,600m² façade

The serrated pyramid aesthetic demanded exacting accuracy to achieve both architectural intent and Passivhaus performance.

High‑Accuracy Installation

To meet the zero‑tolerance requirements:

Hilti laser technology was used to line and level bracket systems
Prefa panels were cut onsite with millimetre precision
Rockwool insulation was installed tightly butted, with no gaps
All inspections were recorded through Kier’s Procore digital platform

These measures ensured consistent quality and supported successful air‑testing for certification.

Phased Delivery Across a Large, Multi‑Elevation Site

The scale of the building required a carefully structured programme. Our approach included:

Full‑time contract management presence onsite
Specialist labour squads working sequentially through each build‑up layer
Daily coordination meetings to manage access and minimise trade clashes
Bulk material orders and direct full‑load deliveries to protect programme and reduce environmental impact

This efficient phasing ensured continuity across all elevations and supported the safe installation of complex features.

Supporting a Sustainable, Community‑Focused Build

The roofing and cladding package plays a crucial role in delivering:

A highly insulated, airtight envelope
Reduced operational carbon aligned with Edinburgh’s net‑zero strategy
Long‑term thermal and acoustic performance
A durable exterior designed for future generations

The project also generated £1.8m in social value, including jobs, training, community engagement and the on‑site Constructing Futures Academy, where pupils gained first‑hand construction experience.

A Landmark Project for Scottish Education

Currie Community High School stands as a flagship Passivhaus development, showcasing Procladd’s expertise in delivering:

Technically demanding building envelopes
Precision‑led roofing and cladding installations
Collaborative working with architects, contractors and certifiers
High‑quality workmanship across complex, large‑scale projects

We are proud to have contributed to a facility that sets a new benchmark for sustainable school design in Scotland and supports an ambitious, community‑driven educational environment.
